ECW 50 Hybrid is considered to be Europa’s latest proposal in curtain wall systems. It is available in two versions (standard or structural glazing), with the mullion’s depth starting at 14mm reaching 250mm and width to 50mm. It is high a performance system with a modern or retro design to choose from and provides an easy construction and installation process.
PRODUCT
PROFILE
CHARACTERISTICS
CHARACTERISTICS
- Available mullions 14-250mm.
- Wide range of tr ansoms 6-205mm.
- Special category mullions-tr ansoms with minimal design (I.D.).
- Available in standard and structur al versions.
- Glass pane usage with thickness 10-50mm.
- Full recyclable double- extrusion rubber (EPDM-Expanded EPDM) for maximum thermal insulation.
- Capacity to meet all requirements according to KENAK (Greek Regulation for the Energy Efficiency of Buildings).
- Multi-degree angle construction.
- Increased thermal and sound insulation.
FEATURES
FEATURES
Aluminium alloy: EN AW 6060 T6 / EN AW 6060 T66
Hardness: 12 Webster
Minimum coating thickness: 75μm
Profile thickness: 1,4-6mm
Tolerance according to: EN 12020-02
Mullion length: 14-250mm
Transom length: 6-205mm
Sash-Frame polyamide width: 14-16mm
Maximum sash width parallel projected window: 10-50mm
Maximum sash weight opening window: 150Kgr
Maximum sash weight projected window: 130Kgr
Maximum sash weight parallel projected window: 200Kgr
