Three (3) automated extrusion lines with an annual production capacity of 35,000 tons of aluminum profiles.

The robust choice in opening systems for enhanced thermal insulation!
Robust construction. Impressive thermal insulation coefficients. Modern aesthetics. In short, a triple advantage solution with the EOS 78 Hybrid system, the latest system from Europa in opening aluminum architectural systems with 42mm polyamide. Fans of both modern and classic lines will be equally satisfied, as the product is available in profiles with either a straight line for modern aesthetics or a curved line that references the classic style.
An important feature is the option to install a multilocking mechanism, providing greater security for the space.
The profile design with a hidden sash offers a minimal aesthetic result in window applications.
Special profiles also allow for the construction of entrance doors.
PRODUCT DETAILS
PRODUCT
PROFILE
CHARACTERISTICS
CHARACTERISTICS
- Modern or classic aesthetics with profiles available in straight or curved lines.
- Enhanced security with the option of a Multilocking Mechanism.
- Exceptionally high thermal and sound insulation performance through:
- Option for double or triple glazing up to 70mm thick.
- Additional insulation between the glazing.
- Extra insulation between the polyamide strips.
- Use of co-extruded gaskets, fully recyclable (EPDM – Expanded EPDM).
- Minimal aesthetic with the option for a hidden sash for uniformity.
- Seamless movement both inward and outward, with a sleek design and the option for low thresholds in balcony doors and entrance doors.
- For situations where a combination of sliding and opening systems is required in the same space, the system can be combined with the ESS 47 Hybrid series and the premium ESS A40 Hybrid.
FEATURES
FEATURES
Aluminum alloy: EN AW 6060 T6
Hardness: 12 Webster
Minimum coating thickness: 75μm
Profile thickness: 1,3-2mm
Dimensional tolerances according to: EN 12020-02
Frame dimensions: 78mm x 53mm
Glass sash dimensions: 86mm x 75mm
Glazing thickness: 24-70mm
Polyamide width: 42mm
Frame thermal transmittance coefficient: Uf from1,1 up to1,9 W/m2K
Sash width range with Camera Europea: 405-1600mm
Sash width range with Multilocking Mech.: 330-1400mm
Sash height range with Camera Europea: 520-2800mm
Sash height range with Multilocking Mech.: 280-2600mm
Maximum sash weight with Camera Europea: 90/130/160/200kg
Maximum sash weight with Multilocking Mech.: 80/100/150kg
TYPES
TYPES

Single sash

Double sash with plisse insect screen

Single sash door with panel

Double sash

Double sash with shutter

Single sash with fixed sash

Double sash with roller shutter & insect screen

Single sash with outward-opening
SECTIONS
SECTIONS
